Tri-claw hauloff
Main Specifications
|
Total Power (KW)
|
4
|
|
Total Weight (kg)
|
1000
|
|
Dimensions (mm)
|
3316×1260×1750
|
Quadri-Pedrail Hauloff
Big pulling force, especially good for PE-x tubes and UPVC thin-wall tubes; evenly-distributed pulling force and reducing deforming
Main Specifications
|
Pulling Force (N)
|
12000 |
|
Pressing Force (N)
|
20000 |
|
Pulling Speed (m/min)
|
0.1-6 |
|
Total Power (kw)
|
5.5 |
|
Tube Range (kw)
|
Ø50-Ø450 |
|
Total Weight (kg)
|
200 |
Hex-Pedrail Hauloff
It can be used as tri-pedrail hauloff. The length meter controls the cutting unit. At the same time, it also control the wall thickness of tube.
Main Specifications
|
Pulling Force (N)
|
2500 |
|
Pulling Speed (m/min)
|
0.1-5 |
|
Driving Power (kw)
|
5.5 |
|
Total Power (kw)
|
8 |
|
Total Weight (kg)
|
3600 |
